0.22uf 1200VDC dc 링크 커플링 필름 캐패시터 필터
담당자 : Cecilia
전화 번호 : +86 18922170847
WhatsApp : +8618922170847
상세 정보 |
|||
수용량: | 0.22uF | 전압: | 800VDC |
---|---|---|---|
사이즈(W*T*H): | 18*8.4*16.5mm | 피치: | 15mm |
모형: | C52801224JX08-01 | 상표: | GDHY |
포장: | 플라스틱 상자 | 맨끝: | CP 철사 |
수용량 포용력: | 광저우 | 인증: | ISO,SGS |
물자: | Polypropylnen 영화 | 시리즈: | DC-LINK 축전기 |
고유의 장소: | 중국 | 색깔: | 황색 |
캡슐에 넣기: | 방연제 에폭시 수지 | 신청: | UPS, 변환기 전원공급기, 용접기 전력 공급기, 전기 자동차 |
하이 라이트: | 800VDC dc 링크 필름 콘덴서,0.22uF dc 링크 축전기,인버터를 위한 0.22uF 축전기 |
제품 설명
Reference Standards | GB/T 17702, IEC 61071 |
Operating Temperature Range | -40℃~85℃ |
Capacity Range | 5.0μF ~ 90μF |
Rated Voltage | 500VDC~1200VDC |
Capacity Tolerance | ±5%(J); ±10%(K) |
Test Voltage between Terminals | 1.5UN(DC)60S 25℃±5℃ |
Test Voltage btw Terminals & Case | 1000+2×UN/√2(VAC) 50Hz 60S (min 3000VAC) |
Dissipation Factor | tgδ≤1.5×10-3 at 25℃±5℃,100Hz |
Insulation Resistance | C•R≥5000S,at 100VDC,25℃±5℃,60S |
Life Expectancy | 100000h at Ur and ≤70℃ |
Application
● Widely used in DC-Link Circuits as a filter for Energy Storage.
● Ups, Inverter Power Supplies, Welder Power Supplies, etc.
Feature
● Polypropylene film dielectric
● Plastic shell, flame retardant epoxy resin encapsulation
● Tin coated copper wire
● High pulse current withstand capacity
● Convenient installation
Product Picture
Production Shape
Production Process
Workshop& Equipment
Company Exhibition
Certification
Packing Method
